E8PC Drucksensoren

CAD Zeichnungen
EPLAN-Teiledaten
E8FC_E8PC Datenblatt

IoT-Drucksensoren

Erkennen Anzeichen von Unregelmäßigkeiten im Kühlwasser und Hydrauliköl durch gleichzeitiges Messen von Druck und Temperatur

Erfassung von Druck und Temperatur zur Vermeidung von plötzlichen Produktionsstopps und Herstellungsfehlern
Auswahl an Ersatzadaptern für einen unkomplizierten Austausch Ihrer aktuellen Druck- und Durchflussmesser
Analoger Stromausgang und IO-Link-Datenübertragung ermöglichen Eigendiagnosen auf Defekte im Sensor selbst

Spezifikationen & Bestellinfo

Ordering Information

Sensors

Applicable fluid 2 The applicable fluid is a liquid that do not erode the liquid contact part materials (such as water, glycol solution, and oil).	Rated pressure range	Control output	Communication method	IO-Link baud rate	Order code
Liquid and gas	-0.1 to 1 MPa	PNP	IO-Link Analog	COM2 (38.4 kbps)	E8PC-010D-E
		PNP	IO-Link Analog	COM3 (230.4 kbps)	E8PC-010T-E
		NPN	Analog	–	E8PC-010-E
Liquid	0 to 10 MPa	PNP	IO-Link Analog	COM2 (38.4 kbps)	E8PC-100D-E
		PNP	IO-Link Analog	COM3 (230.4 kbps)	E8PC-100T-E
		NPN	Analog	–	E8PC-100-E
	0 to 40 MPa	PNP	IO-Link Analog	COM2 (38.4 kbps)	E8PC-400D-E
		PNP	IO-Link Analog	COM3 (230.4 kbps)	E8PC-400T-E
		NPN	Analog	–	E8PC-400-E

Note:

Please contact your OMRON sales representative regarding the IO-Link setup file (IODD file).

Adapters

It must be selected from the adapters below.

Appearance	Type	Nominal diameter of thread 2 The nominal diameter of the thread is the size of the part shown below on the adapter.		Thread type	Materials	Order code
Appearance	Type	Nominal diameter A	Nominal diameter B	Thread type	Materials	Order code
	R1/8 male	6 A	1/8"	R (taper thread)	SUS304	E8PC-YA-A18
	R1/4 male	8 A	1/4"	R (taper thread)	SUS304	E8PC-YA-A14
	R3/8 male	10 A	3/8"	R (taper thread)	SUS304	E8PC-YA-A38
	G1/4 female	8 A	1/4"	G (parallel thread)	SUS304	E8PC-YA-B14N
	NPT1/8 male	6 A	1/8"	NPT (taper thread)	SUS304	E8PC-YA-C18
	NPT1/2 male	8 A	1/4"	NPT (taper thread)	SUS304	E8PC-YA-C14

Cables (Sensor I/O Connectors)

A Cable is not provided with the Sensor. It must be ordered separately.

Type	Appearance	Cable	Order code
Socket on one cable end	Straight	2 m	XS5F-D421-D80-F
	Straight	5 m	XS5F-D421-G80-F
	L-shaped	2 m	XS5F-D422-D80-F
	L-shaped	5 m	XS5F-D422-G80-F
Socket and plug on cable ends 2 Straight type/L-shape type combinations are also available.	Straight/straight	2 m	XS5W-D421-D81-F
	Straight/straight	5 m	XS5W-D421-G81-F
	L-shaped/l-shaped	2 m	XS5W-D422-D81-F
	L-shaped/l-shaped	5 m	XS5W-D422-G81-F

Note:

Refer to Sensor I/O Connector/Sensor Controller on your OMRON website for details.

Throttle (for replacement)

If the excessive pulsation or surge voltage is expected, use a throttle. Install it inside the adapter and use.

Appearance	Type	Material	Order code	Installation method
	For a male adapter	SUS304	E8PC-YS
	For a female adapter	SUS304	E8PC-YS-N

O-ring (for replacement)

Appearance	Type	Order code
	For E8PC-010⬜	E8PC-YL-1 2 Provided with the sensor.
	For E8PC-100⬜/-400⬜	E8PC-YL-2 2 Provided with the sensor.
	Female for adapter G1/4	E8PC-YL-3

Specifications

Sensors

Model	PNP(COM2)	E8PC-010D-E	E8PC-100D-E	E8PC-400D-E
	PNP(COM3)	E8PC-010T-E	E8PC-100T-E	E8PC-400T-E
	NPN	E8PC-010-E	E8PC-100-E	E8PC-400-E
Pressure monitoring 2 The pressure precision is defined based on the values measured in the ordinary temperature environment (approx. 23°C) using water at the ordinary temperature (approx. 23°C).	Rated pressure range	–0.1 to 1 MPa	0 to 10 MPa	0 to 40 MPa
	Display range	–0.20 to 1.10 MPa	–0.10 to 11.00 MPa	–0.10 to 44.00 MPa
	Withstand pressure 2 Even instantaneous pressure fluctuation such as water hammer must be within the withstand pressure. If instantaneous pressure fluctuation is expected, use the throttle included in the package.	4 MPa	30 MPa	50 MPa
	Burst pressure	8 MPa	60 MPa	80 MPa
	Display resolution	0.001 MPa	0.01 MPa	0.01 MPa
	Applicable fluid temperature 2 If the pipe temperature exceeds 70°C, do not contact any cables with the pipe.	–20 to +100°C (no icing or condensation)
	Pressure response time 2 The maximum actual response time has error of 1 ms when the set response time is 3 to 10 ms, 5 ms when it is 11 to 100 ms, and +5% when it is 101 ms or more.	Control output: Select 3 to 6000 ms Analog output: Set value + 2 ms (90% response)
	Pressure monitoring precision	±1.0% of F.S. or less
	Pressure repeatability 2 The pressure repeatability is the error of the detection point when pressure is applied repeatedly in the ordinary temperature environment (approx. 23°C) using water at the ordinary temperature (approx. 23°C) in the rated pressure range.	±0.3% of F.S. or less
	Ambient temperature characteristics 2 The ambient temperature characteristics are prescribed based on the value measured using oil as applying a pressure value of 50% of the maximum rated pressure.	±0.6% of F.S./10°C
	Hysteresis	Variable
	Pressure type	Gauge pressure
Temperature monitoring 2 The temperature monitoring precision is prescribed based on the value measured using water. Temperature measurements are affected by both of the temperatures, the medium and the piping. Temperature measuring elements are installed on the back surface of the piezoelectric element (inside the product) and used to measure the temperature. It might take long for the measured value to get stable according to the heat transmission speed.	Temperature monitoring rated range	–20 to 100°C
	Temperature monitoring precision	±4°C
	Temperature repeatability	±1°C
Control output judgment (selectable)	Standard mode	Judge if the measured value is the threshold value or more (or less).
Control output judgment (selectable)	Window mode	Judge if the measured value is within the upper and lower limits.
Compatible fluid		Gas and fluid not corroding the material of the wetted part (such as water, glycol solution, and oil)
Display method		Numerical value indication: 4-digit 7-segment white LED with inverting function Status indicator: Normal operation (green), status indication (orange), and error (red) The content of status indication is selectable. Output indicator: OUT1 operation (orange), OUT2 operation (orange) Unit indication: E8PC-⬜⬜⬜⬜: MPa (white), E8PC-⬜⬜⬜⬜-E: MPa (white), bar (white), psi (white), °C (white) IO-Link indicator: Lighting when communications are in progress (green)
Delay setting		1 to 9999 ms (Select a function from invalid, ON delay, OFF delay, and one-shot.)
Connection method		M12, 4-pole connector type
Connecting diameter		G3/4 male (Use the optional adapter to convert the diameter) Connection strength 20 N·m
Output ch1 (selectable)	Control output	Pressure control output (N.O./N.C.) E8PC-⬜⬜⬜D/T: PNP E8PC-⬜⬜: NPN 30 VDC or less, Class 2, max. 100 mA, residual voltage 1 V or less
Output ch2 (selectable)	Control output	Pressure control output (N.O./N.C.) / temperature control output (N.O./N.C.) E8PC-⬜⬜⬜D/T: PNP E8PC-⬜⬜: NPN 30 VDC or less, Class 2, 100 mA max., residual voltage 1 V or less
	Analog current output 2 Do not connect analog current output with the master unit of IO-Link. Otherwise, the unit might fail.	Pressure analog output / Temperature analog output Current output 4 to 20 mA (maximum load resistance 350Ω or less) (Display value ± 2% of F.S.)
	External input	One-point teaching, zero point adjustment input (selectable, initial status: invalid) short-circuit current 1.5 mA or less, input time 20 ms or more
IO-Link	IO-Link specification	Ver 1.1
	Baud rate	E8PC-⬜⬜⬜D: COM2 (38.4kbps) E8PC-⬜⬜⬜T: COM3 (230.4Kbps)
	Data length	PD Size: 6 byte OD Size: 1 byte (M-sequence type: TYPE_2_V)
	Minimum cycle time	E8PC-⬜⬜⬜D (COM2): 3.2 ms E8PC-⬜⬜⬜T (COM3): 2.0 ms
Power supply	Power supply voltage	10 to 30 VDC (including 10% ripple (p-p)), Class 2
Power supply	Power consumption	1,200 mW or less (When power supply voltage is 30 V, current consumption must be 40 mA or less. When power supply voltage is 10 V, current consumption must be 120 mA or less.)
Protection circuit		Power supply reverse connection protection, output short-circuit protection, and output reverse connection protection
Environment resistance	Ambient temperature range	–20 to 80°C in operation and storage, respectively (no condensation)
	Ambient humidity range	–35 to 85%RH in operation and storage, respectively (no condensation)
	Vibration resistance (destruction)	1000 VAC, 50/60 Hz, 1 min. between current-carrying parts and case
	Shock resistance (destruction)	10 to 2000 Hz, double amplitude 1.5 mm, 2 hours in X/Y/Z direction each
	Impact (endurance)	500 m/s², three times in X/Y/Z direction each
	Protective structure	IP67
	Pollution degree	3
	Altitude	2,000 m or less
	Installation place	Indoor
Material	Wetted part	Pressure port: SUS304L, diaphragm pressure port: Al₂O₃ (alumina), O-ring: FKM
Material	Other than wetted part	Head: PPSU, display unit: PES, button: PBT, chassis: SUS304L
Weight		Approx.190 g
Accessories		Throttle (Model E8PC-YS and E8PC-YS-N), one each O-ring × 1 (Model E8PC-010: Model E8PC-YL-1, Model E8PC-100/400: Model E8PC-YL-2) Ferrite core × 1 (TDK's Model ZCAT1730-0730A) User's manual (Japanese, English, and Chinese), one each Compliance sheet Index list

Dimensions

Sensors

IoT Pressure Sensor E8PC-⬜⬜⬜-E

Adapter

E8PC-YA-A⬜⬜, E8PC-YA-C⬜⬜

Model	E8PC-YA-A18	E8PC-YA-A14	E8PC-YA-A38	E8PC-YA-C18	E8PC-YA-C14
Thread	G3/4×R1/8	G3/4×R1/4	G3/4×R3/8	G3/4×NPT1/8	G3/4×NPT1/4
A	43.3	47.1	47.6	43.3	47.1
B	21.1
C	13
D	9.2	13	13.5	9.2	13
E	34
F	3.7	4.8	5	3.7	4.8
G	17	17	19	17	17

E8PC-YA-B14N

Throttle

E8PC-YS

E8PC-YS-N

O-ring

E8PC-YL-1

E8PC-YL-2

E8PC-YL-3

Cable

Please refer to E8FC.

Kabel und Zubehör

XS2

XS2-Verbindungskabel mit wasserdichten, einseitigen M12-Kabeln/Verlängerungskabeln

XS3

XS3-Verbindungskabel mit einseitigen M8-Kabeln/Verlängerungskabeln haben geringere Wartungsanforderungen.

IDC-Steckverbinder vom Typ XS5C/XS5G-D418 wurden speziell für den schnellen, einfachen Anschluss ohne spezielle Werkzeuge entwickelt. Erforderlich sind nur ein Drahtschneider und zwei Schraubenschlüssel.
